Product details description
*Products support customization
(see parameter table)the specific gravity is subject toconsultation at the time of ordering!
| Vehicle type | PT-1 | PT-2 | PT-3 | PT-5 | PT-8 | PT-10 | PT-15 |
| Rated deadweight（t） | 1 | 2 | 3 | 5 | 8 | 10 | 15 |
| Loading countertop （L*W*H）（mm） | 2000*1000*500 | 2500*1250*520 | 2800*1400*600 | 3000*1500*780 | 3400*1700*800 | 3400*1700*800 | 3800*2000*800 |
| Wheel track(mm) | 820 | 1100 | 1200 | 1300 | 1450 | 1450 | 1650 |
| Wheelbase(mm) | 1200 | 1400 | 1600 | 1700 | 1900 | 1900 | 2100 |
| Tyre specification | 4.00-8 | 4.00-8 | 5.00-8 | 6.50-10 | 23×9-10 | 23×9-10 | 23×9-10 |
| Number of tires | 4 | ||||||
| Minimum turning radius(mm) | 1950 | 2500 | 2700 | 3100 | 3600 | 3600 | 4100 |
| Hook height from ground(mm) | ＞100 | ＞120 | ＞140 | ||||
| Banister height(mm) | 800 | 850 | 900 | 950 | 950 | 950 | 1000 |
| Total length(mm) | 2800 | 3400 | 3800 | 4000 | 4500 | 4500 | 4900 |
| Self weight(kg) | 360 | 520 | 680 | 1200 | 1500 | 1750 | 2250 |
| Vehicle type | PT-20 | PT-30 | PT-40 | PT-50 | PT-60 | PT-80 | PT-100 |
| Rated deadweight（t） | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
| Loading countertop （L*W*H）（mm） | 5000*2000*900 | 6000*2500*950 | 7000*2500*1000 | 8000*2800*1050 | 8000*2800*1100 | 8000*3000*1150 | 12000*3000*1200 |
| Wheel track(mm) | 1650 | 1650 | 1650 | 1650 | 1650 | 2350 | 2350 |
| Wheelbase(mm) | 3500 | 4200 | 4900 | 5600 | 5600 | 5600 | 8400 |
| Tyre specification | 23×9-10 | 23×9-10 | 23×9-10 | 23×9-10 | 28×9-15 | 28×9-15 | 28×9-15 |
| Number of tires | 8 | 12 | 16 | 20 | 20 | 24 | 30 |
| Minimum turning radius(mm) | 5500 | 6500 | 7500 | 8500 | 8500 | 8500 | 12500 |
| Hook height from ground(mm) | ＞140 | ||||||
| Banister height(mm) | 1000 | ||||||
| Total length(mm) | 6700 | 7700 | 8700 | 9700 | 9700 | 9700 | 13700 |
| Self weight(kg) | 3000 | 4000 | 5000 | 6000 | 7000 | 8000 | 12000 |
