Product details description
*Products support customization
(see parameter table)the specific gravity is subject toconsultation at the time of ordering!
| Electric tractor Technical Parameters | 3tons | 5tons | 10tons | 15tons | 20tons | 30tons | |
| Specification parameters | |||||||
| Size parameters | length*width*height(mm) | 2500*1200*1500 | 2500*1200*1500 | 2500*1200*1500 | 2800*1500*1500 | 2800*1500*1500 | 3000*1800*1500 |
| wheelbase（mm） | 1500 | 1500 | 1500 | 1800 | 1800 | 2000 | |
| mini turning radius（mm） | 2500 | 2500 | 2500 | 2500 | 2500 | 2500 | |
| mini ground clearance（mm） | 140 | 140 | 220 | 220 | 220 | 220 | |
| body weight | 1.2 | 1.8 | 2.2 | 3.5 | 4.5 | 6 | |
| Stuctural parameters | |||||||
| Motor | type of motor | DC series excition | |||||
| motor power | 3 | 5 | 8 | 15 | 16.6 | 28 | |
| Speed | maximum speed | 18 | 15 | ||||
| speed regulation | stepless speed regulation | ||||||
| Run | climbing ability | 10%*20 | 10%*20 | 10%*20 | 15%*5 | 15%*5 | 15%*5 |
| Turning mode | electronic boost | hydraulic power assist | |||||
| braking mode | hydraulically | Vacuum-assisted hydraulics | pneumatic brake | ||||
| drive mode | gearboxes | Gearboxes or drive shafts | drive shafts | ||||
| Power supply system | |||||||
| battery | type of battery | lithium iron phosphate battery | |||||
| battery capacity | 48V/200AH | 48V/330AH | 72V/330AH | 72V/440AH | 80V/440AH | 80V/630AH | |
| charging | charging power source | 380 | |||||
| charging time | 6h-8h | ||||||
| range(full load) | 40km | ||||||
| Control system | |||||||
| controls | motor driver | XINDALI | |||||
| controllers | KAILI | ||||||
